The well-balanced drive system

The Active Line is ideal for all those who want moderate support during everyday eBike use. The Active Line also makes the perfect team with the Purion, Intuvia, Kiox, Nyon on-board computers and with the Bosch eBike system 2 Bosch eBike batteries. Experience controlled acceleration with a barely audible drive.

Silent cruising

A lightweight and quiet Bosch motor provides even more fun without annoying background noise.

Three eBike riders riding behind each other pass a harbor, in the background you can see ships.

Easy handling

The innovative drive concept makes the Drive Unit less than 3 kg and, thanks to its compact size, improved integration into the bicycle frame. The low center of gravity in the middle of the eBike ensures easy handling. The Active Line is compatible with derailleur or hub gears. The optional backpedal function for hub gears helps you to brake extra comfortably.

Close-up of Active Line on a turquoise eBike.

Award winning product design

Flowing forms and smooth lines: The eBike system Active Line received the Red Dot Award for Product Design 2017.

Technical data
	Active Line (BDU310)⁷
eBike system	Bosch eBike system 2
Shifting system type	Derailleur system, hub gear system
Max. support (%)	250 %
Maximum possible drive torque	40 Nm
Start-up behavior	harmonious
Max. supported speed	25 km/h
Backpedal brake	Derailleur system: no, Hub gear system: optional
Walk assist with Hill Hold	j
Hill start assist with Hill Hold	j
Gear shift detection	Hub gear system: no, Derailleur system: yes
Weight, approx.	2,9 kg
Rated continuous output	250 W
Maximum power	290 W
Max. power at a cadence of 70 rpm	290 W
Max. power-to-weight ratio, approx.	100 W/kg

¹Maximum values: Deviations possible, depending on the hub gear system and battery. The eBiker can activate/deactivate the riding modes via the eBike Flow app, the bicycle manufacturer or the specialist dealer. A maximum of four riding modes, in addition to Off mode, can be activated. Using the custom riding modes, the modes can be configured according to the individual needs of the eBiker, via the eBike Flow app.
Exception gear shift detection: eShift hubs

² Maximum values: Deviations possible, depending on the hub gear system and battery. The performance values of this drive unit may be lower upon delivery. They can be increased and customised using the eBike Flow app. It should be noted that higher performance values can lead to increased wear and have a negative effect on the range.
The eBiker can activate/deactivate the riding modes via the eBike Flow app, the bicycle manufacturer or the specialist dealer. A maximum of four riding modes, in addition to Off mode, can be activated. Using the custom riding modes, the modes can be configured according to the individual needs of the eBiker, via the eBike Flow app.
Exception for gear shift detection: eShift hubs.

⁴Maximum values: Deviations possible, depending on the hub gear system and battery. The eBiker can activate/deactivate the riding modes via the eBike Flow app, the bicycle manufacturer or the specialist dealer. A maximum of four riding modes, in addition to Off mode, can be activated. Using the custom riding modes, the modes can be configured according to the individual needs of the eBiker, via the eBike Flow app.
There is no backpedal function for the derailleur system, but it is optional for the hub gear system.
Exception for gear shift detection: eShift hubs

⁵ Maximum values: Deviations possible, depending on the hub gear system and battery. The eBiker can activate/deactivate the riding modes via the eBike Flow app, the bicycle manufacturer or the specialist dealer. A maximum of four riding modes, in addition to Off mode, can be activated. Using the individual riding modes, the modes can be configured according to the individual needs of the eBiker, via the eBike Flow app. There is no backpedal function for the derailleur system, but it is optional for the hub gear system.
Exception for gear shift detection: eShift hubs

⁶ Maximum values: Deviations possible, depending on the hub gear system and battery. The maximum support of 600% relates to speeds of up to 15 km/h and can be increased in the Race, Turbo, eMTB+, Cargo and Auto riding modes. The values can be set individually to a limited extent using the eBike Flow app. It should be noted that higher performance values can lead to increased wear and have a negative effect on the range.
The eBiker can activate/deactivate the riding modes via the eBike Flow app, the bicycle manufacturer or the specialist dealer. A maximum of four riding modes, in addition to Off mode, can be activated. Using the custom riding modes, the modes can be configured according to the individual needs of the eBiker, via the eBike Flow app.
Exception gear shift detection: eShift hubs

⁷ The various riding modes are activated/deactivated by the bicycle manufacturer and the specialist dealer. A maximum of four riding modes, in addition to Off mode, can be activated in the display. Using the individual riding modes, the modes can be configured according to the individual needs of the eBiker, via the eBike Flow app. It's not possible to customise your riding mode on S-pedelecs.

⁸ Maximum values: Deviations possible, depending on the hub gear system and battery. Activation/deactivation of the various riding modes is carried out by the bicycle manufacturer and the specialist dealer. A maximum of four riding modes, in addition to Off mode, can be activated in the display. Using the individual riding modes, the modes can be configured according to the individual needs of the eBiker, via the eBike Flow app. It's not possible to customise your riding mode on S-pedelecs.

⁹ Maximum values: Deviations possible, depending on the hub gear system and battery. The maximum support of 600% relates to speeds of up to 15 km/h and can be increased in the Race, Turbo, eMTB+, Cargo and Auto riding modes. The performance values of this drive unit may be lower upon delivery. They can be increased and customised using the eBike Flow app. It should be noted that higher performance values can lead to increased wear and have a negative effect on the range.
The eBiker can activate/deactivate the riding modes via the eBike Flow app, the bicycle manufacturer or the specialist dealer. A maximum of four riding modes, in addition to Off mode, can be activated. Using the custom riding modes, the modes can be configured according to the individual needs of the eBiker, via the eBike Flow app.
Exception for gear shift detection: eShift hubs.

¹⁰ Maximum values: Deviations possible, depending on the hub gear system and battery. The maximum support of 600% relates to speeds of up to 15 km/h and can be increased in the Race, Turbo, eMTB+, Cargo and Auto riding modes.
The eBiker can activate/deactivate the riding modes via the eBike Flow app, the bicycle manufacturer or the specialist dealer. A maximum of four riding modes, in addition to Off mode, can be activated. Using the custom riding modes, the modes can be configured according to the individual needs of the eBiker, via the eBike Flow app.
Exception for gear shift detection: eShift hubs

¹¹ The weight refers to the pure motor weight of the Hub Line – without control unit and cadence sensor. Support is based on intelligent sensor fusion, which is why maximum support is not specified as a percentage. Maximum values: Deviation possible depending on battery. The eBiker can activate/deactivate the riding modes via the eBike Flow app, the bicycle manufacturer or the specialist dealer. A maximum of four riding modes, in addition to Off mode, can be activated.
