Two people on loaded eBikes ride along a gravel path. The woman in the foreground smiles as she rides through a dry, hilly landscape.

The batteries of the Bosch PowerPack Rack 500 and PowerPack Rack 400 are shown with a cutaway view.

Mounted on or under the luggage rack

Easy to reach when standing

More freedom of movement

Easy to get on and off

Convenient charging

Easy removal and convenient charging directly on the eBike

High energy density

Compact with 205 watt hours per kilogram

The compact, lightweight Bosch PowerPack Rack batteries impress thanks to their ease of use – especially in urban traffic.

Link

Close-up of a luggage rack and a taillight attached to an eBike.

The battery of Bosch PowerPack Rack 500 shown cut free.

PowerPack 500 Rack

This rack battery delivers plenty of energy for spontaneous rides and small excursions. Further advantages include its compact size and light weight.

Energy content approx.	500 Wh
Weight, approx.	2.8 kg
4A Charger	100% charge: Approx. 4.5 hours

To the product comparison

The battery of Bosch PowerPack Rack 400 shown in a cutaway view.

PowerPack 400 Rack

This rack battery is your enduring everyday companion and is ideal for your daily needs. It scores points thanks to its compact dimensions and light weight.

Energy content approx.	400 Wh
Weight, approx.	2.7 kg
4A Charger	100% charge: Approx. 3.5 hours

To the product comparison

The battery of Bosch PowerPack Rack 500 shown cut away.

PowerPack 500 Rack

With the energy of the PowerPack 500 Rack, you are well equipped for long distances and spontaneous rides. Even if the route is a little longer or hillier than planned.

Energy content approx.	500 Wh
Weight, approx.	2.7 kg
Standard charger	100% charge: Approx. 4 hours

Der Akku von Bosch PowerPack Rack 400 freigeschnitten dargestellt.

PowerPack 400 Rack

The PowerPack 400 Rack is compact and durable. With its energy content of approximately 400 Wh, it is the ideal companion for your daily needs.

Energy content approx.	400 Wh
Weight, approx.	2.6 kg
Standard Charger	100% charge: Approx. 3.5 hours

The battery of Bosch PowerPack Rack 300 shown in a cutaway view.

PowerPack 300 Rack

The PowerPack 300 Rack is lightweight and durable. With its energy content of approximately 300 Wh, it provides you with reliable support on short journeys.

Energy content approx.	300 Wh
Weight, approx.	2.6 kg
Standard charger	100% charge: Approx. 2.5 hours

Convenience guaranteed – when inserting, removing and charging.

Open modal

Technical data
	PowerPack 300	PowerPack 400	PowerPack 500	PowerPack 400 Rack	PowerPack 500 Rack
System	Bosch eBike system 2	Bosch eBike system 2	Bosch eBike system 2	The smart system	The smart system
Mounting type	Luggage rack	Luggage rack	Luggage rack	Luggage rack	Luggage rack
Voltage	36 V	36 V	36 V	36 V	36 V
Capacity	8.2 Ah	11.1 Ah	13.4 Ah	10.8 Ah	13.6 Ah
Energy content	Approx. 300 Wh	Approx. 400 Wh	Approx. 500 Wh	Approx. 400 Wh	Approx. 500 Wh
weight	Approx. 2.6 kg	Approx. 2.6 kg	Approx. 2.7 kg	Approx. 2.7 kg	Approx. 2.8 kg
Size (L x W x D)	372 x 122 x 80 mm	372 x 122 x 80 mm	372 x 122 x 80 mm	376 x 122 x 64 mm	376 x 122 x 64 mm
Compatible with DualBattery of the Bosch eBike system 2	No	Yes	Yes	No	No
Compatible with DualBattery of the smart system	No	No	No	Yes	Yes
12A Charger	x	x	x	50% charge: Approx. 1 hours	50% charge: Approx. 1.2 hours
4A Charger	x	x	x	50% charge: Approx. 1.5 hours 100% charge: Approx. 3.5 hours	50% charge: Approx. 1.7 hours 100% charge: Approx. 4.5 hours
2A Charger	x	x	x	50% charge: Approx. 2.8 hours 100% charge: Approx. 6 hours	50% charge: Approx. 3.6 hours 100% charge: Approx. 7.3 hours
Compact Charger	50% charge: Approx. 2 hours 100% charge: Approx. 5 h	50% charge: Approx. 2.5 hours 100% charge: Approx. 6.5 hours	50% charge: Approx. 3.5 hours 100% charge: Approx. 7.5 hours	x	x
Standard Charger	50% charge: Approx. 1 hours 100% charge: Approx. 2.5 hours	50% charge: Approx. 1.5 hours 100% charge: Approx. 3.5 hours	50% charge: Approx. 2 hours 100% charge: Approx. 4 hours	x	x
Fast Charger	50% charge: Approx. 1 hours 100% charge: Approx. 2.5 hours	50% charge: Approx. 1 hours 100% charge: Approx. 2.5 hours	50% charge: Approx. 1.2 hours 100% charge: Approx. 3 hours	x	x

An eBike model with a glass design shows how the Bosch PowerPack rack is positioned and integrated on the luggage rack, and the PowerPack Frame is placed on the frame. Both batteries are highlighted in black to demonstrate the DualBattery function, which means combining two batteries.

DualBattery

Use two batteries for even more range: DualBattery is ideal for long distances and eBikes with higher energy consumption such as Cargo eBikes and S-Pedelecs.

More about DualBattery

View of a smartphone showing the battery level being set for when the goal is reached via the eBike Flow app.

No more range anxiety

Plan your route in the eBike Flow app with Range Control: Select how full your battery should be on arrival.

Discover Range Control

Focus on a smartphone where settings for Battery Lock are adjusted in the eBike Flow app.

Lock the battery digitally

Battery Lock also protects your battery digitally: in the event of theft, it can no longer be used.

Discover Battery Lock

A mountain biker sits at a table on a café terrace and connects his Bosch eBike battery, the PowerTube 800, to the 12A charger. Next to the battery is a coffee cup, with palm trees and Mediterranean architecture visible in the background.

Charge batteries efficiently

Whatever you're planning, whether it's quickly getting back onto the trail, your next ride through the city or another leg of your trek – we have the right charger for you. Letting you charge your eBike efficiently.

Discover chargers

Close-up of a luggage rack and taillight attached to an eBike.

For many years of service

With our smart system batteries, eBikers still have 80% of the original battery capacity available after 1,000 charging cycles.¹ 1,000 charging cycles correspond to a mileage of approx. 45,000 km. With an average distance travelled of approx. 85 km per week; this means that the battery capacity is still 80% even after more than 10 years of use.²

A Bosch CompactTube 400 lies on a wooden table and is gently wiped with a cloth.

Battery safety

Safety is our top priority – including our rechargeable batteries. Take a look at the contribution we make and what you can do.

More about battery safety

PowerPack 400 and PowerPack 500 shown separately.

Rack battery

Thanks to their higher positioning on the eBike, rack batteries can be removed and charged conveniently while standing.

Current product

PowerPack 800 and PowerPack 725 shown separately.

Frame battery

Because it is a frame battery, the PowerPack is easy to access and remove. Thanks to its low centre of gravity, it ensures balanced weight distribution.

About the product

CompactTube 400 and PowerTube 800 shown isolated.

Integrated battery

The Bosch PowerTube batteries blend ideally into the sleek design of your eBike – for high demands in terms of power and aesthetics. Our integrated batteries are installed horizontally or vertically, directly in the frame tube of your eBike.

About the product

All batteries

Vikram Godbole smiles at the camera while standing in a contemporary building.

Vikram Godbole provides information and tips12 questions about the eBike battery

You remove the PowerTube 750 from the frame of your eBike.

Everything you need to know about Bosch batteriesBattery Guide

A cyclist on an eBike rides through an impressive cityscape. The dynamic, low-angle shot highlights the contrast between a state-of-the-art curved glass building and historic architecture under blue skies.

Your safety. Our priority.eBike battery safety

Based on laboratory measurements over 1000 charging cycles at 80 % discharge and 25 °C ambient temperature. Applies to all batteries in the smart system (exception: PowerMore 250). Depending on the battery, the maximum remaining capacity may also be lower. This data relates only to cyclical ageing and not to calendar ageing.
Back
Basis of calculation: eMTB with Performance Line CX (BDU384Y) and PowerTube 800 with performance upgrade. A precise service life cannot be predicted as this is influenced by a variety of factors. Depending on the battery, the service life and maximum remaining capacity may also be lower. This data relates only to cyclical ageing and not to calendar ageing.
